The N2 – Nami Fixations deck support is a structural support designed to attach a deck beam installed parallel to the foundation, while preserving the building's integrity. Designed for decks running along the house, it allows you to create a solid and durable structure without having to screw the rim joist directly into the concrete wall.

Thanks to its design for a beam parallel to the foundation, the N2 support ensures efficient load transfer between the deck structure and the concrete base, while offering great design flexibility. It is particularly suitable for low or elevated decks that follow the facade of the house, as well as for projects where one wishes to limit penetrations in the exterior cladding to reduce the risk of water infiltration.

Made of corrosion-resistant steel, the N2 support is designed to withstand Quebec's climatic conditions and freeze-thaw cycles. Its geometry facilitates beam alignment, which simplifies installation and allows both contractors and self-builders to achieve a professional, clean, and straight result.

The N2 deck support is recommended for decks running along the house, decks with attached railings or pergolas, and projects where the visual continuity of the beam parallel to the foundation is important, while maintaining good structural performance.

Main features:

• Deck support for beam parallel to the foundation
• Allows anchoring the deck structure near the foundation without directly attaching the joist to the concrete wall
• Promotes efficient load transfer to the concrete base and good deck rigidity
• Corrosion-resistant material, suitable for outdoor structures
• Simple, repeatable installation compatible with other Nami Fixations systems
• Ideal for decks along the house, elevated decks, pergolas, and railings

Benefits for your deck projects:

• Preserves the building envelope by limiting penetrations in the foundation and exterior cladding
• Offers a clean and professional solution for beams parallel to the house
• Improves the durability and stability of the structure through well-positioned anchoring
• Suitable for residential projects where aesthetics, longevity, and structural performance are priorities

Choose the N2 – Nami Fixations deck support for your deck projects along the house and enjoy a solid, durable structure that respects the integrity of your building.

Installation guide here

The NP3 Patio Support – Beam Perpendicular to Foundation – Nami Fixations is a professional-grade structural support designed to attach a beam directly to the foundation when the patio structure is perpendicular to the house. Ideal for low-rise decks and ground-level patios, it provides a strong, durable, and engineer-validated anchor without compromising the integrity of the foundation or exterior cladding.

The NP3 model has a load capacity of up to 3,000 lbs and is covered by a 25-year limited warranty, making it a reliable solution for demanding residential projects. Made of galvanized steel, it resists corrosion and the harsh Quebec climate, while ensuring consistent performance over the years.

Its specific design for perpendicular beams allows for the installation of decks in confined spaces, with anchors positioned on each side of the beam’s bearing. The NP3 support limits the cutting of the insulated formwork and reduces the risk of water infiltration by allowing only the end of the beam to pass through the cladding.

Construction Highlights:

• Structural support for beams perpendicular to the foundation.
• Load capacity of up to 3,000 lbs, engineer-validated.
• Direct anchoring to the concrete foundation (minimum 6 in. thick, 15 MPa).
• Ideal for low patios, ground-level decks, and confined spaces.
• Design that limits cutting of insulated formwork and reduces the risk of water infiltration.
• Possible distance between two supports up to 7 ft, depending on the structure's design.
• Simple and quick installation, with a cost-effective labor concept.

Technical Specifications:

• Material: galvanized steel for high corrosion resistance.
• Capacity: up to 3,000 lbs per support, when installed with the provided anchors.
• Application: starter beam perpendicular to the foundation, for wood patio structures.
• Required Foundation: concrete slab or wall at least 6 in. thick, minimum 15 MPa; do not install on block foundations.
• Maximum recommended distance between two supports: up to 7 ft, depending on the structure's load calculation.
• Warranty: 25-year limited warranty offered by Nami Fixations.

Box Contents and Installation:

• 1 NP3 Patio Support – Nami Fixations.
• Concrete anchors provided for fastening the support to the foundation (mandatory use to maintain the certified capacity of 3,000 lbs).

Key Installation Steps (Summary):

• Determine the final height of the deck and mark the position of the supports on the foundation.
• Drill with a 1/2 in. drill bit, 1/2 in. deeper than the anchor length.
• Securely attach the NP3 support against the concrete with the provided anchor screws.
• Insert the wooden beam into the support and fasten it with the recommended hardware, then continue with the patio structure.
• For projects submitted to an engineer or the municipality, load calculations can be made using a reference load of 100 lb/sq ft based on the deck surface area and the capacity of each support.

Benefits for the User:

• Professional solution approved in Quebec, designed to preserve the foundation and exterior cladding.
• Reduced installation time thanks to a simple, repeatable, and economical system.
• Better management of water infiltration due to minimal beam penetration into the building envelope.
• Ideal for contractors, carpenters, and self-builders looking for a proven system, with technical documentation and installation guides available.

User guide available HERE

Nami Fixations' NP4 patio support is a professional-grade structural solution designed to securely fasten a patio beam installed perpendicular to the foundation. Ideal for deck and patio projects requiring higher load capacity, this support ensures a stable connection between the patio structure and the building while preserving the foundation's integrity.

Designed to meet the demands of modern residential construction, the NP4 support effectively transfers beam loads to the foundation, improving the structure's rigidity and longevity. Its configuration for perpendicular beams is particularly valued in projects where space is limited or when the patio needs to be anchored directly to the concrete wall without relying on a supported joist.

Made of high-quality steel with corrosion protection (galvanization or coating depending on the model), the NP4 support is perfectly suited to Quebec's climatic conditions. Its design facilitates precise and repeatable installation, which reduces labor time and helps contractors and self-builders deliver solid and durable projects.

This support is recommended for patios and decks that need to bear heavier loads: spas, pergolas, heavy furniture, or high-traffic areas. Combined with a structural plan that complies with current standards, the NP4 support contributes to the overall safety and performance of the deck.

Key Features:

• Designed for beams perpendicular to the foundation
• Structural support for heavy loads (demanding patios, spas, pergolas, etc.)
• Direct anchoring to concrete foundation for maximum stability
• Corrosion-resistant material, suitable for Quebec climate
• Simple and quick installation with appropriate hardware
• Ideal for elevated decks and outdoor structures subjected to significant loads

Benefits for your patio projects:

• Robust connection between patio and house, validated by structural design
• Reduced risk of water infiltration due to minimal penetration into the building envelope
• Professional solution appreciated by contractors and carpenters
• Perfect for projects subject to municipal approval or engineer review

Choose Nami Fixations' NP4 patio support for your heavy-load decks and ensure a reliable, safe, and durable structure.

User guide available HERE

The NP5 – Nami Fixations patio support is a high-performance structural support designed to attach a patio beam perpendicular to the foundation in the most demanding projects. Designed for decks and patios with heavy loads, it ensures a robust connection between the structure and the building, while preserving the integrity of the foundation and exterior cladding.

The NP5 support allows for highly efficient load transfer from the beam to the concrete foundation, improving the rigidity, stability, and durability of the deck. Its perpendicular beam configuration is ideal when the patio needs to be anchored directly to the concrete wall or slab, for example, for elevated structures or installations with a spa, pergola, or roof terrace.

Made of quality steel with corrosion protection, the NP5 is designed to withstand Quebec's climatic conditions and freeze-thaw cycles. Its design facilitates precise and repeatable installation, reducing labor time and allowing both contractors and self-builders to achieve a professional result.

This support is recommended for projects where structural capacity and safety are priorities: large decks, patios with concentrated loads, high-traffic areas, structures with posts or additional load-bearing elements.

Main features:

• Patio support for beam perpendicular to the foundation.
• Designed for heavy loads and demanding patio structures.
• Direct anchoring to concrete foundation for maximum stability.
• Corrosion-resistant material, suitable for the Quebec climate.
• Simple and quick installation with appropriate hardware.
• Ideal for elevated decks, patios with spas, pergolas, and heavy-load outdoor structures.

Advantages for your patio projects:

• Robust structural connection between the house and the patio, suitable for projects subject to engineering or municipal approval.
• Reduced risk of water infiltration thanks to optimized joint with the foundation and minimal penetration into the building envelope.
• Professional solution appreciated by contractors, carpenter-joiners, and self-builders.
• Perfect for long-term landscaping projects where the reliability and durability of the structure are essential.

Choose the NP5 – Nami Fixations patio support for your heavy-load decks and ensure a safe, rigid, and durable structure, perfectly adapted to the requirements of modern construction.

* Only the use of these anchors allows for the 5000 lbs certification of the support.

User guide HERE

The N56 elevated 6" x 6" post support – Nami Fixations is a structural support designed to raise 6" x 6" posts off the ground, protecting the wood from moisture and damage caused by direct contact with concrete or soil. This type of support is ideal for patios, decks, pergolas, railings, and other outdoor structures requiring a solid and durable base for posts.

Installed in an elevated position, the N56 support lifts the post while ensuring efficient load transfer to the foundation or concrete base. This configuration reduces the risk of rot, deformation, and movement of the wood, while contributing to the overall stability of the structure. The support is specifically designed for 6" x 6" posts, guaranteeing a precise fit and reliable fastening.

Made of corrosion-protected steel, the N56 support is suitable for Quebec's climatic conditions and perfect for permanent structures exposed to the elements. Its design facilitates post alignment and leveling, making installation quicker and more professional, both for contractors and self-builders.

This support is recommended for projects where aesthetics and durability are important: patios with wooden railings, pergolas, roof terraces, shelters, and other constructions requiring a solidly anchored 6" x 6" post.

Key features:

• Elevated 6" x 6" post support
• Lifts the post to limit contact with the ground and moisture
• Designed for efficient load transfer to the foundation or concrete base
• Corrosion-resistant material, suitable for outdoor structures
• Helps maintain post alignment and verticality
• Ideal for patios, pergolas, railings, shelters, and wooden structures

Benefits for your projects:

• Improves the durability of 6" x 6" posts by limiting wood rot
• Provides a professional and aesthetic base for elevated structures
• Simplifies post installation and adjustment on site
• Suitable for residential projects where solidity and appearance are priorities

Choose the N56 elevated 6" x 6" post support – Nami Fixations for stable, durable, and well-protected posts in your patio and outdoor living projects.

* Only the use of these anchors allows for the 5000 lb certification of the support.
